Mung beans sorting equipment,with japan's nikon camera and SMC's air filter! Vision's production, From anhui!

FOB Reference Price:Get Latest Price
US $40,000-60,000 / Pieces | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Beans color sorter machine
Use:
Mung bean sorting
Certification:
CE,ISO9001
Place of Origin:
Anhui, China (Mainland)
Brand Name:
VISION
Model Number:
VSN3000-G6A
Condition:
New
After-sales Service Provided:
Engineers available to service machinery overseas
CCD camera:
Japan Nikon Camera
Air Filter:
SMC
Power Switch:
Schneider Electric
FPGA:
Altera CO.,LTD
Provide Service:
Make To Order
Supply Ability
Supply Ability:
40 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard wooden box(vacuum package for color sorter)
Port
shanghai
Lead Time :
15~20 days since confirm the order

Specifications

1.low waste & high accuracy
2.Superb After-sale Service
3.passed ISO 9001 certificaton
4.Professional Technical Guidance



  550685485_940







BEI





1. The color sorter uses 2048 high performances CCD sensors with resolution up to 0.07mm²;
2. The sorter adopts high quality special industrial lenses designed and manufactured for color sorting of  Mung Bean  ;
3. The high speed DSP technology provides the sorter with fast detection and high identification rate;
4. Master control system adopts ARM high-end embedded processor, effectively enhance control speed and color selection precision;
5. Overall unit adopts intelligent closed-loop control;
6. The operation interface adopts industrial grade 7-inch TFT contact screen and features simple parameters setting and easy operation;
7. High speed air valve is used to ensure quick response, low power consumption and long service life;
8. Sorters use intelligent temperature and air pressure control technology in order to ensure the best operative mode for the whole machine;
9. Failure alarm automation and modular construction makes easy repair;



10.Business Cooperation: Most of the machine parts are imported(Altera CO.,LTD FPGA,

Japan.Proface,CKD,SMC,Schneider).



 CDK



 initpintu_















Product Model/Technical parameter:



Model

VSN3000-G3A

VSN3000-G4A

VSN3000-G5A

VSN3000-G6A

Channels

192

256

320

384

Capacity (t/h)

2~5

3.5~7

4.5~8

5~10

Accuracy

>99.98%

>99.98%

>99.98%

>99.98%

Waste

<1:0.125

<1:0.125

<1:0.125

<1:0.125

Voltage(v)

~220V 50Hz

~220V 50Hz

~220V 50Hz

~220V 50Hz

Power(kw)

2.5

2.5

2.8

3.1

Pressure(M Pa)

≥0.6

≥0.6

≥0.6

≥0.6

Consumption(L/min)

1200~3000

1200~3000

1600~3500

1800~3800

Weight(kg)

900

1000

1200

1400

Dimension(L×W×H)

1425×1518×1880

1725×1518×1880

2025×1518×1880

2325×1518×1880
